Hot Dip Galvanized Hatch Cover Chain – Alloy Steel Marine-Grade Safety Chain
Specially engineered for marine and industrial applications, our Hot Dip Galvanized Hatch Cover Chain is manufactured from high-strength alloy steel with a protective hot-dip galvanized finish for superior corrosion resistance. Available in standard diameters from 13mm to 30mm, these chains can also be customized in link size and configuration to meet specific client requirements. Ideal for securing hatch covers, cargo holds, and access points, these chains offer reliable performance under demanding conditions.
TECHNICAL SPECIFICATIONS – HOT DIP GALVANIZED CHAIN
| Diameter | Inside Length (mm) | Inside Width (mm) | Proof Load (kN) | Breaking Load (kN) | Weight (kg/m) |
|---|---|---|---|---|---|
| 11 | 43 | 12.5 | 57 | 116 | 2.39 |
| 14(A) | 50 | 17 | 97 | 194 | 3.95 |
| 14(B) | 42 | 18 | 97 | 194 | 4.32 |
| 15 | 42 | 21 | 106 | 212 | 5.2 |
| 16(A) | 55 | 22 | 128 | 254 | 5.34 |
| 16(B) | 55 | 18 | 128 | 254 | 5.29 |
| 18(A) | 54 | 24 | 161 | 322 | 7.12 |
| 18(B) | 64 | 25 | 161 | 322 | 6.32 |
| 19 | 57 | 24 | 164 | 330 | 7.6 |
| 20(A) | 60 | 22 | 129 | 359 | 9.5 |
| 20(B) | 62 | 22 | 179 | 359 | 8.57 |
| 22(A) | 78 | 31 | 240 | 480 | 9.86 |
| 22(B) | 86 | 30 | 240 | 480 | 9.24 |
| 22(C) | 66 | 31 | 240 | 480 | 10.6 |
| 30 | 108 | 35 | 399 | 798 | 18.22 |
Please Note: The description might be incorrect, please contact us for confirmation.
