German Standard Roller Fairlead – Precision-Engineered for Professional Marine Applications
Superior Rope Guidance with German Engineering
Our DIN-compliant German Standard Roller Fairlead is available in multiple configurations to meet diverse mooring needs:
✔ 4-Roller Fairlead – Ideal for standard wire rope handling
✔ 5-Roller & 6-Roller Fairlead – Enhanced directional control
✔ 12-Roller Fairlead (Custom) – For specialized heavy-duty applications
Optimized for Various Vessel Types:
• Container Ships
• Tankers
• Bulk Carriers
• Dry Cargo Vessels
• Small Boats & Workboats
Parameters:
| Type | Weight （kg) | Wire Φ | A | B | C | D | E | F | G | H | I | K | L |
| CF2 | 75 | 12 | 180 | 100 | 650 | 80 | 446 | 170 | 10 | 465 | 208 | 80 | 356 |
| CF3 | 130 | 16 | 230 | 130 | 800 | 100 | 546 | 210 | 10 | 575 | 258 | 100 | 446 |
| CF5 | 220 | 20 | 250 | 130 | 900 | 120 | 626 | 250 | 15 | 655 | 308 | 120 | 506 |
| CF8 | 330 | 24 | 280 | 160 | 1000 | 140 | 716 | 290 | 20 | 730 | 328 | 120 | 576 |
| CF12 | 580 | 32 | 300 | 160 | 1200 | 180 | 836 | 366 | 25 | 855 | 398 | 140 | 676 |
| CF20 | 1100 | 40 | 320 | 180 | 1350 | 245 | 1030 | 500 | 35 | 1045 | 505 | 180 | 830 |
| CF32 | 2210 | 48 | 400 | 250 | 1700 | 300 | 1236 | 610 | 45 | 1260 | 583 | 200 | 1016 |
The description/sizes may be different with goods, please check with us when order.
