Geared Trolley
| Model | GCL‑B0.5T | GCL‑B1T | GCL‑B2T | GCL‑B3T | GCL‑B5T |
|---|---|---|---|---|---|
| Capacity (t) | 500 | 1000 | 2000 | 3000 | 5000 |
| Running test load (KN) | 7.35 | 14.7 | 29.42 | 44.13 | 61.29 |
| Min radius of curve (m) | 0.9 | 1 | 1.2 | 1.3 | 1.4 |
Dimensions (mm)
| Parameter | GCL‑B0.5T | GCL‑B1T | GCL‑B2T | GCL‑B3T | GCL‑B5T |
|---|---|---|---|---|---|
| A | 225 | 252 | 300 | 360 | 392 |
| B | 173 | 188 | 226 | 290 | 313 |
| C | 292 | 300 | 310 | 324 | 329 |
| D | 377 | 385 | 395 | 409 | 414 |
| E | 292.5 | 302.5 | 319.5 | 354 | 365 |
| F | 383 | 393 | 398 | 425.5 | 430.5 |
Adjustable beam width (mm)
| Parameter | GCL‑B0.5T | GCL‑B1T | GCL‑B2T | GCL‑B3T | GCL‑B5T |
|---|---|---|---|---|---|
| M | 64–220 | 64–220 | 88–220 | 102–220 | 114–220 |
| 160–305 | 160–305 | 160–305 | 160–305 | 160–300 |
Net weight (kg)
| Parameter | GCL‑B0.5T | GCL‑B1T | GCL‑B2T | GCL‑B3T | GCL‑B5T |
|---|---|---|---|---|---|
| (a) | 13.3 | 15.9 | 23.2 | 37.7 | 48.9 |
| (b) | 13.7 | 16.4 | 24.0 | 38.8 | 50.3 |
Volume (cm³)
| Parameter | GCL‑B0.5T | GCL‑B1T | GCL‑B2T | GCL‑B3T | GCL‑B5T |
|---|---|---|---|---|---|
| (a) | 33×29×24.5 | 33×29×24.5 | 38.5×33×29 | 39×38×35 | 46.5×39×37 |
| (b) | 42×29×24.5 | 42×29×24.5 | 46×33×29 | 46×38×35 | 53×39×37 |
Description:
GCL‑B type geared trolleys have 5 specifications from ½ t to 5 t. The geared trolley is hand‑operated by pulling the hand chain, running on the bottom flange of a monorail, with the screw hanger to adjust the width of the I‑beam. They are widely used in factories, mines, wharves, docks, warehouses and engine rooms for installation of equipment and conveyance of goods. They are especially suitable for maintenance and repairing of equipment in places where no power supply is available.
Note: The description may be different with the product, please contact us for quotation.
