Five Rollers Fairlead

CB/T 3062-2011 Five Rollers Fairlead Type C – Heavy-Duty Mooring Solution

Optimized for High-Load Mooring Operations

The Five Rollers Fairlead (Type C) is engineered to CB/T 3062-2011 standards, providing superior rope guidance for steel wire (14–44mm) and nylon ropes (36–100mm). With five precision rollers, it ensures smooth directional changes while reducing rope wear in demanding marine environments.

✔ High Load Capacity (54kN–533kN) – Built for commercial vessels and heavy-duty applications
✔ Wide Roller Size Range (100–320mm) – Accommodates various rope diameters
✔ Durable Construction – Made from marine-grade cast steel & steel plate
✔ CB/T 3062-2011 Certified – Guaranteed compliance with Chinese marine standards

Key Features & Benefits

🔹 Model: Five Rollers Fairlead Type C
🔹 Rollers: 5 smooth-operating rollers for minimal friction
🔹 Material: Heavy-duty cast steel & steel plate
🔹 Standards: Fully compliant with CB/T 3062-2011
🔹 Applications: Ideal for tugboats, offshore vessels, and commercial ships

Parameters:

Nominal Dia.	Nylon Rope Dia.	SWL KN	Steel Wire Dia.	Weight (kg)	B	B1	B2	D	H	H1	L	L1	L2	L3	t
100	36	54	14	139	324	194	108	102	508	250	644	416	300	544	10
120	40	70	16	209	384	232	128	121	552	270	728	456	320	608	12
140	45	89	18	284	415	250	138	140	606	310	776	480	330	646	14
150	70	110	20	410	475	288	158	152	670	330	880	540	370	730	16
160	80	133	22	541	507	308	168	168	710	360	940	580	400	780	18
180	85	186	26	723	571	345	190	194	770	380	1030	620	420	850	20
200	95	216	28	931	632	385	210	219	820	410	1136	686	460	936	22
230	100	282	32	1253	723	445	240	245	910	450	1256	746	490	1026	25
260	100	357	36	1852	815	500	270	273	1000	500	1430	850	560	1170	28
320	100	533	44	2877	997	620	330	325	1130	570	1690	990	640	1370	30
