FISHING CHAIR
HA – F – 200 & HA – F – 100
Centre Console – Leaning Post – Flip Back – Large (HA – F – 200)
| Part No. | Description | Colour | Frame Colour | Vinyl Swatch No. | Overall Dimensions W×D×H (mm) |
|---|---|---|---|---|---|
| HA – F – 200.1 | Centre Console Flip Back | Silver | 1035×1190×596 | ||
| HA – F – 200.2 | Centre Console Flip Back | BLACK | 1035×1190×596 |
Features:
- Perfect for multipurpose boats that require fore and aft positioning.
- Engineered and built to last, using aerospace 6061 aluminium.
- Strong and rugged 2″ (50.8mm) tubing.
- Thick plates offer generous cross bracing and structural support.
- Anodised aluminium or black powder coat finish.
- Rubber stoppers to prevent rattling.
- Washers provide smooth travel of the back rest front and back.
- Fits up to an 80ltr cooler box with rear bar removed.
Centre Console – Leaning Post (HA – F – 100)
| Part No. | Description | Colour | Frame Colour | Vinyl Swatch No. | Overall Dimensions W×D×H (mm) |
|---|---|---|---|---|---|
| HA – F – 100.1 | Centre Console Seat | Silver | 1030×1130×517 | ||
| HA – F – 100.2 | Centre Console Seat | BLACK | 1030×1130×517 |
Visual Information:
- The image shows multiple views of the HA – F – 200 and HA – F – 100 chairs. For HA – F – 200, there are front, side, and back views, as well as a view showing the flip – back mechanism and a technical drawing with dimensions. For HA – F – 100, there are front and side views, along with close – up details of the rubber stoppers and hinges, and a technical drawing with dimensions. The technical drawings provide precise measurements for different parts of the chairs, aiding in installation and understanding of the product structure.
Attention please: The description may be different with the goods, please check with us when order.
