Marine Ductile Iron Angle Globe Valve | JIS F7322C & F7400 5K Certified for Fuel & Lube Oil Systems
Product Overview
Our JIS F7322C marine ductile iron angle globe valve is specifically engineered for precise flow control and backflow prevention in shipboard fuel oil and lubricating oil piping systems. Manufactured to JIS B2220 flange standards, this valve combines the superior strength of ductile iron with optional stainless steel or bronze trim for exceptional performance in marine environments. Ideal for applications requiring reliable shut-off and flow regulation in compact spaces.
Key Features & Benefits
-
Dual JIS Certification: Complies with both JIS F7322C and JIS F7400 standards for marine valves
-
Premium Material Construction: Ductile iron body with optional SUS/bronze disc and SUS/brass stem
-
5K Pressure Rating: Optimal for low to medium pressure marine oil systems
-
Angle Design: Space-saving configuration ideal for compact engine room installations
-
JIS B2220 Flange Compliance: Perfect compatibility with marine piping standards
-
Backflow Prevention: Effectively prevents reflux in fuel and lubricating oil lines
-
IACS Certification: Approved by RINA, ABS, CCS, LR, and BV classification societies
Technical Specifications
-
Standard: JIS F7322C & JIS F7400
-
Flange Standard: JIS B2220
-
Nominal Diameter: DN15 to DN40
-
Pressure Rating: 5K
-
Body Material: Marine Ductile Iron
-
Disc Options: Stainless Steel (SUS) / Bronze
-
Stem Options: Stainless Steel (SUS) / Brass
Applications
-
Shipboard fuel oil transfer and supply lines
-
Lubricating oil piping systems
-
Engine room flow control applications
-
Auxiliary machinery oil systems
-
Marine power generation systems
Quality Assurance
-
Well-Selected Materials: Components meet domestic and international standards
-
Rational Structure: Optimized design for reliable marine operation
-
Aesthetic Design: Professional appearance suitable for modern vessel installations
-
Custom Material Selection: Customer-specified materials available
Dimension Chart (IMPA Code Reference)
| IMPA Code | Model | L | D | C | Bolt Hole Pattern |
|---|---|---|---|---|---|
| 750311 | 7322C 5K15 | 55 | 80 | 60 | 4×φ12 |
| 750312 | 7322C 5K20 | 60 | 85 | 65 | 4×φ12 |
| 750313 | 7322C 5K25 | 65 | 95 | 75 | 4×φ12 |
| 750314 | 7322C 5K32 | 80 | 115 | 115 | 4×φ15 |
| 750315 | 7322C 5K40 | 85 | 120 | 120 | 4×φ15 |
The description/sizes may be different with goods, please check with us when order.
