EU Type Bulwark Mounting Chock

China EU Type Bulwark Mounting Chock – Internationally Certified Marine Mooring Solution

Product Overview

The China EU Type Bulwark Mounting Chock is a premium-grade marine mooring component engineered for global maritime applications. Manufactured from high-strength materials ZG200-400 and ZG230-450, this chock features precision-machined smooth contact surfaces and customizable protective coatings. With comprehensive certification options (BV, CCS, mill certificates) and robust steel pallet packaging, it delivers reliable performance for vessels operating in diverse marine environments worldwide.

Key Features & Benefits

• ✅ Global Export Experience – Proven performance with worldwide distribution network

• ✅ Dual Material Options – ZG200-400 and ZG230-450 for optimal strength and durability

• ✅ International Certification – BV, CCS, and mill certificates available for quality assurance

• ✅ Customizable Surface Protection – Grey Epoxy Primer, Black Bitumen Paint, or custom coating thickness

• ✅ Secure Packaging – Steel pallet packaging ensures damage-free international shipping

• ✅ Precision Surface Finish – Smooth rope contact surfaces prevent line wear and damage

• ✅ Comprehensive Size Range – Multiple dimensions to suit various vessel requirements

Technical Specifications

| Product No. | Dimensions (mm) | | | | | | | Mass (kgs) |
|————-|—————–|-|-|-|-|-|-|-|————|
| | A | B | C | D | E | H | L | N | |
| BME-001 | 315 | 250 | 695 | 630 | 432 | 342 | 168 | 497 | 198 |
| BME-002 | 425 | 280 | 925 | 780 | 516 | 450 | 224 | 661 | 358 |
| BME-003 | 600 | 315 | 1160 | 875 | 571 | 504 | 250 | 866 | 547 |
| BME-004 | 600 | 450 | 1160 | 1010 | 706 | 504 | 260 | 856 | 850 |
| BME-005 | 800 | 600 | 1500 | 1300 | 860 | 580 | 290 | 1060 | 1200 |
| BME-006 | 1000 | 800 | 1760 | 1560 | 1250 | 700 | 350 | 1450 | 1580 |

Material & Coating Specifications

• Primary Materials: ZG200-400, ZG230-450 High-Strength Cast Steel

• Standard Coatings: Grey Epoxy Primer or Black Bitumen Paint

• Custom Options: Available upon request with specified thickness requirements

• Surface Finish: Precision-machined smooth contact surfaces for rope protection

Quality Assurance & Certification

• Quality Control: Strict manufacturing process monitoring

• Certification Options: Bureau Veritas (BV), China Classification Society (CCS), Mill Certificates

• Surface Standards: Smooth finished rope contact surfaces free from imperfections

• Packaging: Secure steel pallet packaging for international shipping

Applications

• Commercial vessel bulwark mounting systems

• Offshore platform mooring installations

• Naval and military ship applications

• Port and terminal mooring points

• Shipyard and new construction projects

• Marine repair and retrofit operations
