CB 3015-83 Engineering Ship Fairlead – Heavy-Duty Solution for Specialized Vessels
Engineered for Demanding Marine Operations
Our CB*3015-83 compliant Engineering Ship Fairlead is specifically designed for:
✔ Dredgers
✔ Crane Ships
✔ Piling Barges
✔ Other Specialized Engineering Vessels
Key Features & Benefits:
• Robust Construction – Cast steel & steel plate for extreme durability
• Precision Rollers (100-300mm diameter) for smooth rope guidance
• Type A & Type B Options to suit different operational needs
• Quality Certified – Meets all CB*3015-83 requirements
Parameters:
| Vertical | Suitable steel wire dia. | Horizontal | Screw hole dia. | L | B | H | b | h1 | h2 | l | |
| Roller Dia. D | Roller Dia.D1 | d | |||||||||
| Type A | Type B | ||||||||||
| 100 | 19.5 | 85 | 22 | 540 | 340 | 240 | 240 | 250 | 220 | 50 | 200 |
| 150 | 26 | 120 | 26 | 760 | 460 | 340 | 340 | 340 | 320 | 65 | 290 |
| 200 | 37.5 | 150 | 32 | 980 | 580 | 430 | 440 | 430 | 410 | 80 | 380 |
| 250 | 48.5 | 200 | 39 | 1220 | 740 | 520 | 550 | 540 | 500 | 110 | 480 |
| 300 | 56 | 250 | 39 | 1460 | 900 | 620 | 675 | 650 | 590 | 135 | 580 |
The description/sizes may be different with goods, please check with us when order.
