Electric Ship Anchor Windlass
Application
The Electric Ship Anchor Windlass is a professional-grade anchoring system designed for mid-sized vessels requiring dual-chain handling capability. It is particularly suitable for:
-
Coastal cargo ships
-
Offshore supply vessels
-
Large yachts & patrol boats
Key Features:
✔ Dual Gypsy System – Handles two Ø34mm anchor chains simultaneously
✔ Sealed Gearbox – IP56 protection against water ingress
✔ Manual Brake/Clutch – Immediate response and control
✔ Electric Drive – 7.5-15kW motor options available
Technical Specifications
| Parameter | Specification |
|---|---|
| Chain Size | Ø34mm (customizable) |
| Motor Power | 7.5-15kW (3-phase) |
| Control Voltage | 24V/110V/220V/440V |
| Gearbox | Helical gear, oil-bath lubricated |
| Brake System | Manual band brake |
Advantages & Features
-
Heavy-Duty Construction
-
Cast steel housing (450MPa yield strength)
-
316L stainless steel wear components (PREN >25)
-
-
Operational Flexibility
-
Local control station (IP56 rated)
-
Optional bridge remote control
-
-
Maintenance Advantages
-
Centralized grease lubrication points
-
Quick-access service panels
-
-
Safety & Reliability
-
Fail-safe brake system
-
Overload protection (mechanical + electrical)
-
-
Certifications
-
IRS, RINA, LR
-
SOLAS compliant
-
| Specifications | |
| Chain diameter(AM2) | 34mm |
| Cable diameter | 38mm |
| Power | 11/11/7.5KW |
| Speed | 1700/810/380r/min |
| Voltage | 400v / 50Hz |
| Working load | 49.1KN |
| Overload | 73.7KN |
| Support load | 294KN |
| Speed | ≥9m/min |
| Drum load | 20KN |
| Drum speed | ≥9m/min |
| Support load | 40KN |
The description/sizes may be different with goods, please check with us when order.
