Electric Anchor Winches – Secure and Efficient Docking Solution
Product Overview
Our Electric Anchor Winches provide reliable and precise vessel securing during docking operations. Designed for quick line adjustment and high load capacity, this winch features a compact, corrosion-resistant design with electric motor power and remote/local control options. Certified by IRS, BV, LR, and other major classification societies, it ensures safe and efficient mooring in all marine conditions.
Key Features & Benefits
✔ High Load Capacity – Handles mooring lines up to 100mm diameter
✔ Electric Motor Efficiency – Low energy consumption with smooth operation
✔ Durable Construction – Stainless steel / coated carbon steel for corrosion resistance
✔ Easy Control – Local panel + wireless remote (IP67 waterproof)
✔ Safety Systems – Automatic tension control, overload protection, and hydraulic brakes
✔ Low Maintenance – Sealed components for reduced wear
Technical Specifications
| Parameter | Specification |
|---|---|
| Drum Capacity | 150m–800m (customizable) |
| Line Diameter | Up to 100mm (varies by model) |
| Motor Power | 5kW–50kW (1/2/3-speed options) |
| Control | Local + Remote (wired/wireless) |
| Certifications | IRS, BV, LR, ABS, DNV (upon request) |
Parameters:
| Rated Pull | Drum Capacity | Motor Power | Rated Speed | |
| T | kN | φmm*m | kW | m/min |
| 0.5 | 5 | φ8*100 | 3/1.2 | ≥12 |
| 1 | 10 | φ10*150 | 4.3/1.7 | ≥12 |
| 2 | 20 | φ14*150 | 8.5/3.5 | ≥12 |
| 3 | 30 | φ16*150 | 11/11/7.5 | ≥15 |
| 4 | 40 | φ18*150 | 16/16/11 | ≥15 |
| 5 | 50 | φ20*200 | 22/22/16 | ≥15 |
| 8 | 80 | φ26*200 | 30/30/22 | ≥15 |
| 10 | 100 | φ28*200 | 45/45/30 | ≥15 |
| 12.5 | 125 | φ30*200 | 45/45/30 | ≥15 |
| 16 | 160 | φ32*250 | 60/60/45 | ≥15 |
| 20 | 200 | φ40*250 | 60/60/45 | ≥9.5 |
| 25 | 250 | φ44*250 | 75/75/36 | ≥9.5 |
| 30 | 300 | φ50*250 | 75/75/36 | ≥7.8 |
| 40 | 400 | φ56*250 | 85/85/64 | ≥7.8 |
| 50 | 500 | φ58*250 | 85/85/64 | ≥6 |
| 60 | 600 | φ64*250 | 85/85/64 | ≥5 |
The description/sizes may be different with goods, please check with us when order.
