Electric Fire Water Monitor | Long-Range Remote-Controlled Firefighting System
Overview:
Our Electric Fire Water Monitor is a high-performance, industrial-grade firefighting solution designed for safe and efficient long-range fire suppression. Powered by reliable DC drive systems, it offers both wired and wireless remote control options, allowing operators to accurately direct water jets from a safe distance. Constructed primarily with durable stainless steel, this monitor ensures excellent corrosion resistance and long-term reliability in demanding environments.
Key Features:
-
Dual Control Modes: Flexible operation via wired or wireless remote control for enhanced safety and adaptability.
-
Long-Distance Operation: Enables precise water jet direction control from remote locations, protecting personnel in hazardous fire scenarios.
-
Multi-Function Suppression: Delivers powerful water jet streams for extinguishing solid combustible fires and water mist for effective cooling and rescue operations.
-
Corrosion-Resistant Construction: Manufactured with premium stainless steel for durability in harsh environments.
-
High-Capacity Flow: Designed for large-flow water delivery to combat significant fire incidents efficiently.
Technical Specifications:
| Model | Flow Range (L/S) | Jetting Range (≥m) | Rated Pressure (Mpa) | Pitching Angle (°) | Rotation Angle (°) | Weight (≤kg) | Connecting Flange |
|---|---|---|---|---|---|---|---|
| PSKD20 | 20 | 48 | 0.8 | -30〜+70 or -70〜+70 | 0-360 | 25 | DN100 |
| PSKD30 | 30 | 55 | 0.8 | -30〜+70 or -70〜+70 | 0-360 | 30 | DN100 |
| PSKD40 | 40 | 60 | 0.8 | -30〜+70 or -70〜+70 | 0-360 | 30 | DN100 |
| PSKD50 | 50 | 65 | 0.8 | -30〜+70 or -70〜+70 | 0-360 | 45 | DN100 |
| PSKD60 | 60 | 70 | 1.0 | -30〜+70 or -70〜+70 | 0-360 | 45 | DN100 |
| PSKD70 | 70 | 75 | 1.0 | -30〜+70 or -70〜+70 | 0-360 | 45 | DN100 |
| PSKD80 | 80 | 85 | 1.0 | -30〜+70 or -70〜+70 | 0-360 | 45 | DN100 |
| PSKD100 | 100 | 90 | 1.2 | -30〜+70 or -70〜+70 | 0-360 | 55 | DN150 |
| PSKD120 | 120 | 95 | 1.2 | -30〜+70 or -70〜+70 | 0-360 | 55 | DN150 |
| PSKD150 | 150 | 100 | 1.4 | -30〜+70 or -70〜+70 | 0-360 | 105 | DN200 |
| PSKD180 | 180 | 105 | 1.4 | -30〜+70 or -70〜+70 | 0-360 | 105 | DN200 |
| PSKD200 | 200 | 110 | 1.4 | -30〜+70 or -70〜+70 | 0-360 | 105 | DN200 |
The description/sizes may be different with goods, please check with us when order.
