Double Gypsy Mooring Windlass
Application
The Double Gypsy Mooring Windlass is a heavy-duty anchoring system designed for larger vessels requiring dual-anchor deployment, including:
-
Commercial ships (tankers, cargo vessels)
-
Offshore support vessels
-
Naval & coast guard ships
Key Features:
✔ Dual Gypsy System – Handles two anchor chains simultaneously (Ø20mm-120mm)
✔ Electric Motor Drive – Powerful & consistent operation
✔ Independent/Synchronized Control – Operate one or both gypsies as needed
✔ Optional Warping Head – For additional rope handling
[View detailed specifications here]
Advantages & Features
-
Heavy-Duty Construction:
-
High-strength cast steel / 316L stainless steel
-
Reinforced gearbox for continuous operation
-
-
Flexible Control:
-
Bridge remote control (centralized operation)
-
Local manual override (deck-mounted)
-
-
Low Maintenance:
-
Sealed bearings (IP56 protection)
-
Centralized lubrication system
-
-
Custom Configurations:
-
With/without warping head (for mooring lines)
-
Drum attachment (additional rope management)
-
-
Safety & Reliability:
-
Dual braking system (manual + hydraulic)
-
Load monitoring (prevents over-tensioning)
-
-
Certified Quality:
-
CCS, BV, LR, DNV, ABS approved
-
SOLAS & MED compliant
-
Parameters:
| Part Of Mooring | Part Of Weighing | ||||||
| Warping Head | Nom.Speed | Capacity | W.E.Load | Chain Cable Dia. | Nom.Pull | Anchor Depth | Nom.Speed |
| kN | m/min | m | kN | mm | kN | m | m/min |
| 40 | 13.6 | 110 | 15 | 19 | 15.3 | 82.5 | ≥9 |
| 20.5 | 17.9 | ||||||
| 22 | 20.6 | ||||||
| 20 | 10.5 | 80 | 20 | 24 | 24.5 | 82.5 | ≥9 |
| 26 | 28.7 | ||||||
| 28 | 33.3 | ||||||
| 30 | 38.3 | ||||||
| 40 | 15 | 140 | 30 | 32 | 43.5 | 82.5 | ≥9 |
| 34 | 49.1 | ||||||
| 36 | 55.1 | ||||||
| 50 | 18 | 140 | 40 | 38 | 61.4 | 82.5 | ≥9 |
| 40 | 68 | ||||||
| 42 | 75 | ||||||
The description/sizes may be different with goods, please check with us when order.
