Cone Type Rubber Dock Fender for Marine Applications
The Cone Type Rubber Dock Fender represents the pinnacle of modern marine fender technology, evolving from the highly regarded “Cell Fender” design. This advanced fender system integrates superior energy absorption capacity with remarkably low reaction forces, delivering unparalleled efficiency in protecting vessels and docking structures during berthing operations. Its innovative conical shape ensures exceptional stability under a wide range of loading conditions, including axial, shear, and angular forces, making it the optimal choice for ports and berths that experience significant berthing angles and heavy impact forces.
Key Features:
- Superior Energy Absorption: Designed to absorb high levels of kinetic energy from vessels, minimizing damage to both ships and docking facilities.
- Low Reaction Force: Reduces the force transmitted to the dock structure, enhancing overall safety and longevity.
- Conical Stability: The unique conical geometry maintains structural integrity under diverse loading scenarios, ensuring reliable performance in all weather conditions.
- Versatile Application: Suitable for a variety of berthing scenarios, including those with large berthing angles and heavy impact loads.
- Durable Construction: Made from high-quality rubber materials, these fenders are built to withstand the harsh marine environment, offering long-lasting service.
Technical Specifications:
| Model Number | Height (H, mm) | Diameter (D, mm) | Upper Flange Width (U, mm) | Lower Flange Width (P, mm) | Base Width (S, mm) | Number of Holes |
|---|---|---|---|---|---|---|
| CO500H | 500 | 800 | 490 | 730 | 425 | 4 |
| CO600H | 600 | 960 | 590 | 875 | 515 | 4 |
| CO800H | 800 | 1280 | 785 | 1165 | 685 | 6 |
| CO1000H | 1000 | 1600 | 980 | 1460 | 855 | 6 |
| CO1100H | 1100 | 1760 | 1080 | 1605 | 940 | 8 |
| CO1200H | 1200 | 1920 | 1175 | 1750 | 1025 | 8 |
| CO1300H | 1300 | 2080 | 1275 | 1900 | 1100 | 8 |
| CO1400H | 1400 | 2240 | 1370 | 2040 | 1195 | 8 |
| CO1600H | 1600 | 2560 | 1570 | 2335 | 1365 | 8 |
| CO1800H | 1800 | 2880 | 1765 | 2625 | 1540 | 10 |
FAQs:
Q1: What makes the Cone Type Rubber Dock Fender superior to other fender types?
A1: The Cone Type Rubber Dock Fender combines exceptional energy absorption with low reaction forces, thanks to its conical design. This makes it highly efficient in protecting both vessels and docking structures, especially in scenarios with large berthing angles and heavy impact loads.
Q2: Can the Cone Type Rubber Dock Fender be customized for specific applications?
A2: Yes, we offer customization options for the Cone Type Rubber Dock Fender to meet specific requirements regarding size, material, and mounting configurations. Please contact our sales team for more details.
Q3: How durable is the Cone Type Rubber Dock Fender in harsh marine environments?
A3: The Cone Type Rubber Dock Fender is constructed from high-quality rubber materials that are resistant to saltwater, UV rays, and extreme weather conditions, ensuring long-lasting performance and reliability.
Q4: What is the maintenance requirement for the Cone Type Rubber Dock Fender?
A4: Regular inspection and cleaning are recommended to maintain optimal performance. The fender’s robust construction minimizes the need for frequent repairs or replacements, reducing long-term maintenance costs.
Q5: Are there any installation guidelines for the Cone Type Rubber Dock Fender?
A5: Yes, we provide detailed installation instructions with each fender. It is important to follow these guidelines to ensure proper installation and optimal performance. Additionally, our technical support team is available to assist with any installation queries.
Please Note: The description might be incorrect, please contact us for confirmation.
