DIGITAL/ LIGHT BEAM DISPLAY CONTROLLER

DIGITAL/ LIGHT BEAM DISPLAY CONTROLLER

GENERAL
Controlled by advanced MPU, the device can be applied to display and control the multi physical quantity checking signal. The high brightness LED digital display and resolution ratio (screen format) make the measuring values and controlling values clearer and easy-to-read.

TECHNICAL PARAMETER

1. Input Signal

   • Analogue: Thermocouple, Hot resistance, Current, Voltage, Far transmit pressure resistor

2. Output Signal

   • Analogue output: DC 4mA~20mA, 0~10mA, DC 1V~5V, DC 0~5V

   • Switching value: Relay control output

   • SCR zero-crossing pulse output

   • Solid relay control output

3. Measuring accuracy

   • Digital: ± 0.5%FS ± 1 character

   • Light beam: ± 1%FS

4. Controlling way: upper limit, lower limit, max. upper limit and min. lower limit

5. Environment temperature: -30~70℃

6. Power voltage:

   • Linear power: AC 190V~240V

   • Switch power: AC/DC 90V~265V, AC/DC 22V~26V

Note: The description may be different with the product, please contact us for quotation.
