Combined electric mooring windlass
Application
The combined electric mooring windlass is an advanced anchoring system integrating chain and rope handling capabilities, designed for:
-
Commercial vessels (cargo ships, tankers)
-
Offshore service boats
-
Large yachts & naval vessels
Key Features:
✔ Dual-Function Design – Combines gypsy (chain wheel) + warping drum in one unit
✔ Electric Drive System – Smooth, powerful operation
✔ Bow-Mounted – Optimized for anchor handling & mooring operations
✔ Flexible Configuration – Single or dual drum options
[View detailed specifications here]
Advantages & Features
-
High-Efficiency Design:
-
Integrated gearbox with 20% higher torque than standard models
-
Dual-purpose drum handles both chain (Ø14mm-120mm) and rope (up to Ø50mm)
-
-
Control Options:
-
Bridge remote control (full automation)
-
Local manual override (waterproof deck controls)
-
-
Maintenance Optimized:
-
Self-lubricating bearings (10,000h service life)
-
Quick-release access panels
-
-
Marine-Grade Durability:
-
316L stainless steel components (PREN >25)
-
Saltwater-resistant coatings
-
-
Safety Systems:
-
Dual braking (mechanical + hydraulic failsafe)
-
Load limiter (auto-stop at 110% capacity)
-
-
Certifications:
-
IRS, BV, LR, DNV, ABS
-
SOLAS & MED compliant
-
Parameters:
| Chain Dia.(mm) | Mooring Pull(kN) | Mooring Speed(m/min) | Working Load(kN) | Working Speed(m/min) | Drum Capacity(m) | Motor Power(kW) |
| 14/16/17.5 | 8 | ≥12 | 8.3/10.9/13.0 | ≥9 | Ф11х100 | 4.3/1.7 |
| 19/20.5/22 | 15 | ≥12 | 15.3/17.9/20.6 | ≥9 | Ф13х120 | 8.5/3.5 |
| 24/26 | 20 | ≥12 | 24.5/28.7 | ≥9 | Ф15х120 | 8.5/3.5 |
| 28/30 | 30 | ≥12 | 33.3/38.3 | ≥9 | Ф18х150 | 11/11/7.5 |
| 32/34/36 | 40 | ≥12 | 43.5/49.1/55.1 | ≥9 | Ф20.5х150 | 16/16/11 |
| 38/40/42 | 50 | ≥12 | 61.4/68.0/75.0 | ≥9 | Ф20.5х150 | 22/22/16 |
| 44/46/48 | 60 | ≥12 | 82.3/89.9/97.9 | ≥9 | Ф26х200 | 30/30/22 |
| 50/52/54 | 60 | ≥15 | 106.3/114.9/123.9 | ≥9 | Ф26х200 | 30/30/22 |
| 56/58/60 | 80 | ≥15 | 133.3/143.0/153.0 | ≥9 | Ф26х200 | 45/45/30 |
| 62/64 | 80 | ≥15 | 163.4/174.1 | ≥9 | Ф30х200 | 45/45/30 |
| 66/68 | 100 | ≥15 | 185.1/196.5 | ≥9 | Ф30х200 | 45/45/30 |
| 70/73 | 120 | ≥15 | 208.3/226.5 | ≥9 | Ф32.5х200 | 60/60/45 |
| 76/78 | 125 | ≥15 | 245.5/258.6 | ≥9 | Ф32.5х200 | 60/60/45 |
| 81/84 | 140 | ≥15 | 311.7/335.2 | ≥9 | Ф36х200 | 75/75/36 |
| 78/90 | 150 | ≥15 | 359.5/384.8 | ≥9 | Ф38х200 | 75/75/36 |
| 92/95 | 200 | ≥15 | 402.0/428.7 | ≥9 | Ф40х200 | 85/85/64 |
| 97/100 | 250 | ≥15 | 446.9/475.0 | ≥9 | Ф42х200 | 100/100/50 |
| 105/107 | 300 | ≥15 | 523.7/543.8 | ≥9 | Ф44х200 | 110/110/55 |
| 112/114 | 350 | ≥15 | 595.8/617.3 | ≥9 | Ф48х200 | 132/132/66 |
The description/sizes may be different with goods, please check with us when order.
