Chemical Injection BWTS – 500 m³/h Advanced UV Treatment Solution | IMO & USCG Certified
Product Overview
The Chemical Injection BWTS is a high-performance, eco-friendly solution designed for mid-sized commercial vessels requiring efficient and compliant ballast water treatment. Utilizing a pure physical process combining mechanical filtration and medium-pressure ultraviolet disinfection, this system ensures safe discharge without chemicals or environmental harm. With a flexible treatment capacity of 120–550 m³/h, the BOS-500 offers easy installation, automatic operation, and reliable performance under the most demanding marine conditions.
Key Features & Benefits
-
✅ High-Efficiency Treatment Capacity – 120 to 550 m³/h ideal for medium-sized commercial vessels and offshore support ships
-
✅ Chemical-Free UV Ballast Water Treatment – Environmentally safe physical process with no toxic byproducts
-
✅ USCG & IMO Type Approved BWMS – Fully compliant with international and US Coast Guard ballast water regulations
-
✅ Advanced Self-Cleaning Filter System – Automatic removal of organisms and sediments larger than 50μm
-
✅ Medium-Pressure UV Disinfection Technology – Effectively eliminates aquatic invasive species and pathogens
-
✅ Compact & Flexible Design – Horizontal and vertical configuration options for easy engine room installation
-
✅ Energy-Efficient Operation – Optimized power consumption with automatic control systems
Advanced Treatment Technology
1. Mechanical Filtration Stage
-
Self-Cleaning Filter Unit (Model FH500): Automatically removes organisms, sediments and solids larger than 50µm through negative pressure suction technology
-
Multiple Control Modes: Time-based, pressure-differential, or manual operation for flexible operation
-
Low Maintenance Design: Automatic backflush ensures continuous operation without manual cleaning
2. Ultraviolet Disinfection Stage
-
Medium-Pressure UV Technology (Model UV500): Effectively inactivates aquatic nuisance species (ANS), bacteria, and pathogens
-
Ultrasonic Anti-Scaling System: Omnidirectional cleaning through ultrasonic refraction and diffraction prevents quartz sleeve fouling
-
High-Efficiency Disinfection: Ensures ≥99.9% organism inactivation rate across all water conditions
Technical Specifications
Filter Unit (Model: FH500)
-
Treatment Capacity: 120–550 m³/h
-
Dimensions (W×D×H): 1933 × 816 × 1265 mm
-
Inlet/Outlet Diameter: DN300
-
Configuration Options: Horizontal or vertical installation
-
Filtration Level: >50μm particle removal
UV Unit (Model: UV500)
-
Treatment Capacity: 120–550 m³/h
-
Dimensions (W×D×H): 1100 × 805 × 415 mm
-
Inlet/Outlet Diameter: 300 mm
-
Weight: 308 kg
-
Cleaning System: Ultrasonic anti-scaling technology
System Components
1. Filter Unit
-
Negative pressure self-cleaning filter with automatic backflush
-
Removes large particles, organisms and sediments (>50µm)
-
Three operation modes: time control, pressure control, and manual control
2. UV Disinfection Unit
-
Medium-pressure ultraviolet disinfection chamber
-
Ultrasonic automatic cleaning system for maintenance-free operation
-
Real-time monitoring of UV intensity and system performance
3. Control Unit
-
One-touch automatic operation with manual override capability
-
Continuous system monitoring and data logging
-
User-friendly interface with alarm and diagnostic systems
Certifications & Approvals
The BOS-500 BWMS holds certifications from leading international classification societies:
USCG | BV | CCS | NK | DNV GL | ABS | LR | RINA | RS | IRS
The description/sizes may be different with goods, please check with us when order.
