JCZ-100C Heavy-Duty Marine Centrifugal Ventilation Fan for Ships and Vessels
Product Overview
The JCZ-100C is a robust marine centrifugal fan engineered to deliver high-volume airflow and reliable ventilation across critical shipboard areas. Designed specifically for harsh marine conditions, this fan is ideal for engine rooms, cargo holds, accommodation spaces, and other enclosed environments requiring continuous air exchange. Built with corrosion-resistant materials and a high-efficiency impeller, the JCZ-100C ensures quiet, energy-efficient performance while supporting onboard safety and comfort.
Key Features
-
Marine-Grade Corrosion Resistance: Constructed to withstand saline and humid environments, offering extended service life in demanding conditions.
-
High-Efficiency Centrifugal Design: Delivers powerful airflow with reduced noise levels, ideal for continuous operation in sensitive zones.
-
Variable Speed Control: Compatible with automated and manual speed adjustment to match specific ventilation demands.
-
Easy Maintenance & Repair: Designed for straightforward access to internal components, minimizing downtime and servicing costs.
-
System Integration Ready: Works seamlessly with marine ducting, dampers, filters, and control systems for a complete ventilation solution.
-
Rugged Electric Motor Options: Available in 50Hz/60Hz configurations with power ratings suitable for global vessel standards.
Applications
-
Engine room ventilation and cooling systems
-
Cargo hold air quality management
-
Accommodation and crew area air circulation
-
Marine HVAC auxiliary support
-
Fume and heat extraction onboard commercial and industrial vessels
Operating Conditions
-
Ambient Temperature: -25 ℃ to +55 ℃
-
Max Relative Humidity: 95%
-
Horizontal Rolling: ±45°
-
Vertical Rolling: ±15°
-
Horizontal Tilting: ±15°
-
Vertical Tilting: ±10°
-
Vibration and Impact Resistance: Suitable for dynamic marine environments
Technical Parameters & Dimensions
| Type | Flow Rate (m³/h) | Total Pressure (Pa) | Static Pressure (Pa) | Speed (r/min) | Freq (Hz) | Power (Kw) | Motor Type |
|---|---|---|---|---|---|---|---|
| JCZ-100C | 39,000 | 585 | 490 | 1460 | 50 | 15 | Y160L-4H |
| 42,000 | 530 | 390 | |||||
| 48,000 | 470 | 295 | |||||
| 46,000 | 840 | 705 | 1750 | 60 | 18.5 | Y180M-4H | |
| 50,000 | 765 | 560 | |||||
| 57,000 | 675 | 420 |
Dimensions
-
D₁: Ø1000mm
-
D₂: Ø1070mm
-
D₃: Ø1100mm
-
L: 900mm
-
n*d: 20 x Ø19mm
-
Weight: ≈322 kg (50Hz) / ≈340 kg (60Hz)
The description/sizes may be different with goods, please check with us when order.
