CBM Marine Valves – JIS Standard Equivalent Valves with Comprehensive Maintenance Solutions

Product Overview
CBM Marine Valves offer premium quality marine valve solutions designed with identical face-to-face dimensions and flange standards as JIS marine valves, ensuring perfect compatibility and interchangeability. Our comprehensive product line includes direct equivalents to major JIS standards: CBM1041 (JIS F7350), CBM1078 (JIS F7398), CBM1091 (JIS F7363), CBM1092 (JIS F7366), and CBM1090 (JIS F7367). Each valve is engineered for exceptional performance in demanding marine environments while providing complete maintenance support for extended service life.

Key Product Equivalents

  • CBM1041 Sea Valve → JIS F7350 Standard

  • CBM1078 Self-Closing Valve → JIS F7398 Standard

  • CBM1091 Gate Valve → JIS F7363 Standard

  • CBM1092 Gate Valve → JIS F7366 Standard

  • CBM1090 Gate Valve → JIS F7367 Standard

Professional Valve Maintenance Guidelines

Routine Operational Maintenance

  • Ensure all valve components remain complete and intact during operation

  • Maintain flange and bracket bolts – no looseness permitted with intact threads

  • Tighten handwheel fastening nuts immediately when loose to prevent wear

  • Never replace missing handwheels with adjustable wrenches

  • Keep packing glands properly aligned with appropriate pre-load clearance

  • Install protective covers on valve stems in harsh environments

  • Maintain complete, accurate, and clear valve identification scales

  • Keep insulation jackets intact without sagging or cracks

  • Avoid knocking, standing, or supporting heavy objects on operational valves

Advanced Lubrication Maintenance Procedures

Precision Grease Quantity Management

  • Calculate exact grease requirements based on valve type and size

  • Prevent both under-lubrication (accelerated wear) and over-lubrication (waste)

  • Use precise sealing capacity calculations for optimal grease injection

Pressure Optimization Techniques

  • Monitor pressure patterns during grease injection

  • Address low pressure issues (seal leakage) and high pressure concerns (blockages)

  • Adjust pressure based on seal type – higher for hard seals, lower for soft seals

  • Clean and replace hardened grease using specialized cleaning fluids

Strategic Positioning for Maintenance

  • Maintain ball valves in open position during lubrication

  • Keep gate valves closed to ensure proper grease distribution

  • Verify lubrication effectiveness through operational testing

  • Ensure uniform coating on valve balls and gate surfaces

Comprehensive Safety & Efficiency Measures

  • Perform pressure relief and drainage before grease injection

  • Tighten drain and pressure relief connections post-maintenance

  • Follow sequential grease distribution from nearest to farthest ports

  • Address blockages immediately when abnormal flow patterns occur

Valve-Specific Maintenance Considerations

  • Ensure proper diameter and seal alignment for ball valves

  • Adjust limits considering both open and closed positions

  • Protect grease injection ports from contaminants and oxidation

  • Apply anti-rust coatings to maintenance points

  • Consider medium-specific requirements (gasoline vs. diesel operations)

  • Include valve stem lubrication in maintenance routines

  • Understand directional markings and flow requirements

  • Protect electric actuators from moisture and corrosion

  • Prevent winter freezing damage to transmission systems

  • Avoid forced operation after torque protection activation

The description/sizes may be different with goods, please check with us when order.
