Type A Mooring Buoy Join Shackle for Ship Anchoring
Our high-frequency marine accessory, the Type A Mooring Buoy Join Shackle, is a top-tier shackle specifically designed to connect anchor chains for securely mooring ships to mooring buoys. This robust and reliable shackle is crafted from high-quality steel, available in grades 2 and 3, ensuring exceptional strength and durability. It is compatible with anchor chains having a nominal diameter ranging from 38mm to 90mm, making it suitable for a wide variety of marine applications.
The Mooring Buoy Shackle comes in two types: Type A and Type B. The Type A buoy shackle features a unique design with two legs on the body connected by a sturdy strut. This design allows for easy connection to the common link of anchor chains using a kenter type joining shackle, providing a secure and stable mooring solution.
Comprehensive Marine Hardware Solutions
In addition to our high-quality mooring buoy shackles, we offer a diverse range of marine accessories, including turnbuckles, wire rope clips, thimbles, ratchet straps, and all kinds of marine hardware. We also supply various types of anchors and anchor chains, such as offshore chains, chafe chains, and fittings with diameters ranging from 12.5mm to 130mm. These chains come with accessories like kenter shackles, joining shackles, end shackles, swivels, swivel shackles, and buoy shackles, among others. Our chains are available in grades 2 and 3, approved by renowned classification societies such as CCS, LR, ABS, BV, DNV, NK, and KR, ensuring compliance with international marine safety standards.
Type A Mooring Buoy Shackle Specifications
| Chain Dia (mm) | d | L | L1 | B | B3 | D | h | Testing Load/KN (tf) | Mass (kg) |
|---|---|---|---|---|---|---|---|---|---|
| M1 | M2 | M3 | Type A | Type B | |||||
| 38 | 56 | 395 | 375 | 150 | 372 | 113 | 80 | 406/580.6/812 | 27.8/26 |
| 40 | 58 | 406 | 384 | 375 | 118 | 83 | 448.2/640.4/896.3 | 31.2/29.9 | |
| 42 | 59 | 416 | 394 | 379 | 125 | 85 | 703.1/980.7 | 35.2/34 | |
| … (continue with the rest of the data in the same format) |
FAQs
Q1: What are the key advantages of using a Type A Mooring Buoy Join Shackle?
A1: The Type A Mooring Buoy Join Shackle offers several key advantages, including its robust steel construction, compatibility with a wide range of anchor chain diameters, and secure connection design. Its unique two-legged structure with a strut ensures stability and reliability during mooring operations, making it an ideal choice for marine applications.
Q2: How do I determine the correct size of the mooring buoy shackle for my ship?
A2: To determine the correct size of the mooring buoy shackle, you need to consider the nominal diameter of your anchor chain. Our shackles are available in various sizes to accommodate chains ranging from 38mm to 90mm in diameter. Refer to our product specifications table to select the appropriate shackle size based on your chain diameter.
Q3: Can you provide customized mooring buoy shackles according to my specific requirements?
A3: Yes, we offer customized services for mooring buoy shackles.
Q4: What is the warranty period for your mooring buoy shackles?
A4: Our mooring buoy shackles come with a standard warranty period of [X] years, covering any defects in materials or workmanship. During this period, we will repair or replace any defective shackles free of charge, provided that they have been used and maintained in accordance with our instructions.
Q5: How can I place an order for your mooring buoy shackles?
A5: Placing an order for our mooring buoy shackles is easy. You can send us an inquiry through our website or contact our sales team directly by phone or email. Our dedicated sales representatives will assist you with the ordering process, provide you with a competitive quote, and ensure that your order is processed quickly and efficiently.
Attention please: The description was copied from different cooperating manufacturers. The description may be different with the goods, please check with us when order.
