YWC Series Best Price Marine OWS – IMO MEPC.107(49) Certified 15ppm Bilge Water Treatment System
Product Overview
Our YWC Series Best Price Marine OWS provides advanced oily wastewater treatment for vessels and industrial applications, ensuring full compliance with international environmental regulations. This complete separation system processes bilge water to achieve ≤15ppm oil content output, meeting stringent IMO MEPC.107(49) standards and MARPOL Annex I requirements. The integrated system includes a type-approved 15ppm bilge separator, precision oil content monitor, and automatic shutdown device for reliable operation in demanding marine environments.
Key Applications
• Marine Bilge Water Treatment – Comprehensive oily wastewater processing for all vessel types
• Port and Harbor Facilities – Oil-water separation for dockyards and port operations
• Industrial Wastewater Management – Effective treatment for mining and manufacturing facilities
• Oil Depot Operations – Environmental protection for storage terminal operations
• Commercial Shipping Compliance – Meets international and Chinese domestic wastewater discharge standards
Advanced Technical Specifications
YWC Series Performance Data
| Model | Capacity (m³/h) | Motor Power (kW) | Heater Power (kW) | Discharge Pressure | Suction Head |
|---|---|---|---|---|---|
| YWC-0.25 | 0.25 | 0.37 | 1 | 5-10m H₂O | ≤6m H₂O |
| YWC-0.50 | 0.50 | 0.55 | 3 | 5-10m H₂O | ≤6m H₂O |
| YWC-1.00 | 1.00 | 0.75 | 6 | 5-10m H₂O | ≤6m H₂O |
| YWC-1.50 | 1.50 | 1.1 | 6 | 5-10m H₂O | ≤6m H₂O |
| YWC-2.00 | 2.00 | 1.1 | 6 | 5-10m H₂O | ≤6m H₂O |
| YWC-2.50 | 2.50 | 1.5 | 6 | 5-10m H₂O | ≤6m H₂O |
| YWC-3.00 | 3.00 | 1.5 | 6 | 5-10m H₂O | ≤6m H₂O |
| YWC-4.00 | 4.00 | 2.2 | 12 | 5-10m H₂O | ≤6m H₂O |
| YWC-5.00 | 5.00 | 2.2 | 12 | 5-10m H₂O | ≤6m H₂O |
Additional Models Available
-
YSZ Series: 0.1 to 5.0 m³/h capacity range
-
CYSC107 Series: 0.1 to 2.0 m³/h capacity with plunger pump systems
Power Options: AC380V/50Hz/3Φ, AC415V/50Hz/3Φ, AC440V/60Hz/3Φ, AC480V/60Hz/3Φ
Three-Stage Separation Technology
1. Primary Treatment – Gravity Separation
Bilge water enters under vacuum pressure through our specialized feeding pump system, preventing emulsion formation. Advanced cone plate technology facilitates oil coalescence through gravity separation.
2. Secondary Processing – Depth Filtration
The pre-treated water passes through high-efficiency fiber filters that capture remaining oil particles and fine contaminants through advanced adsorption technology.
3. Final Polishing – Membrane Permeation
Our integrated 15ppm oil content monitor continuously analyzes water quality. If oil levels exceed limits, the system automatically activates third-stage membrane treatment for final purification. Non-compliant water is recirculated through automated pneumatic valves.
Automatic Monitoring & Safety Features
-
Continuous Oil Content Monitoring – Real-time effluent quality analysis
-
Automatic Diversion System – Pneumatic valves redirect non-compliant water
-
Safety Shutdown Protection – Prevents illegal discharge operations
-
Multi-Voltage Compatibility – Adapts to global electrical standards
Compliance & Certification
Our marine oil water separators meet and exceed requirements from:
-
International Maritime Organization (IMO MEPC.107(49))
-
MARPOL Annex I Regulations
-
Chinese Domestic Wastewater Standards
-
Global Classification Society Approvals (CCS, BV, DNV, ABS, LR, GL, KR, RINA, EC)
The description/sizes may be different with goods, please check with us when order.
