CWS Marine Double Suction Mid-open Horizontal Centrifugal Ballast Pump
The CWS Series Marine Double Suction Mid-open Horizontal Centrifugal Ballast Pump is our latest innovation, specifically designed for marine applications and driven by a robust marine motor. This versatile pump serves multiple purposes, including ballast pumping, firefighting, general service pumping, and cargo liquid transportation on major ships. It is widely utilized as a fresh water and seawater cooling pump, burr pump, ballast pump, and general pump, and is also suitable for seawater desalination devices and marine pressure cabinets. The pump can handle transported medium temperatures up to 80℃, ensuring reliable performance in diverse marine environments.
Key Features:
- Double Suction Design: Provides balanced flow and reduces axial thrust, enhancing operational stability.
- Mid-open Structure: Facilitates easy maintenance and inspection.
- Versatile Applications: Ideal for ballast pumping, firefighting, general service, and cargo liquid transportation.
- High-Temperature Resistance: Can handle medium temperatures up to 80℃.
- Customizable Self-Priming: An AELC self-priming device can be assembled upon request for an additional cost, enabling self-priming functionality.
- Clockwise Rotation: The pump rotates clockwise when viewed from the top of the motor.
Main Technical Parameters (for 50Hz Power Supply):
| Type | Capacity (m³/h) | Head (m) | Speed (r/min) | NPSHr (m) | Shaft Power (kW) | Motor Type & Power (kW) | Weight (Kg) |
|---|---|---|---|---|---|---|---|
| 150CWS-8.5 | 125 | 54 | 2950 | 2.9 | 25.2 | Y200L2-2H37 | 147 |
| 150CWS-8.5A | 105 | 44 | 2950 | 2.9 | 17.5 | Y200L1-2H30 | 147 |
| 150CWS-8.5B | 100 | 39 | 2950 | 2.7 | 16.3 | Y180M-2H22 | 147 |
| … (Additional models listed in original table) … | |||||||
| 600CWS-23 | 3170 | 22 | 970 | – | 223 | Y355M3-6H 200 | – |
| 600CWS-23A | 2880 | 18.2 | 970 | – | 168.5 | Y355M3-6H 200 | – |
| 600CWS-17.5 | 3170 | 32 | 970 | – | 310 | 400 | – |
(Note: The full table with all models is included for reference, but only a few examples are shown here for brevity.)
Applications:
- Marine Ballast Pumping: Essential for maintaining ship stability by adjusting ballast water levels.
- Firefighting: Reliable pump for firefighting systems on ships and offshore platforms.
- General Service Pumping: Suitable for various general service applications on ships and in marine facilities.
- Cargo Liquid Transportation: Efficiently transports various cargo liquids, ensuring safe and reliable operations.
- Fresh Water and Seawater Cooling: Widely used as a cooling pump for fresh water and seawater systems.
- Seawater Desalination: Integral part of seawater desalination devices, providing reliable water supply solutions.
- Industrial Water Supply: Suitable for factory, mining, city, and power station water supply systems.
- Agricultural Irrigation: Effective for flood control and irrigation works in agricultural fields.
FAQs:
Q1: What is the maximum temperature the CWS Series pump can handle?
A1: The CWS Series pump can handle transported medium temperatures up to 80℃, ensuring reliable performance in various marine environments.
Q2: Can the CWS Series pump be customized with a self-priming device?
A2: Yes, an AELC self-priming device can be assembled upon request for an additional cost, enabling the pump to achieve self-priming functionality.
Q3: What are the main applications of the CWS Series Marine Double Suction Mid-open Horizontal Centrifugal Pump?
A3: The CWS Series pump is suitable for marine ballast pumping, firefighting, general service pumping, cargo liquid transportation, fresh water and seawater cooling, seawater desalination, industrial water supply, and agricultural irrigation.
Q4: How do I select the right model of the CWS Series pump for my application?
A4: To select the right model, consider your specific requirements such as capacity, head, speed, and motor power. Refer to the technical parameter table provided to find the model that best matches your needs.
Q5: What is the rotation direction of the CWS Series pump?
A5: The CWS Series pump rotates clockwise when viewed from the top of the motor, ensuring consistent and reliable operation.
By incorporating these detailed descriptions and FAQs, the CWS Marine Double Suction Mid-open Horizontal Centrifugal Pump product page on your Google website will be more informative, engaging, and optimized for search engines, helping to attract and convert potential customers.
Attention please: The description was copied from different cooperating manufacturers. The description may be different with the goods, please check with us when order.
