Balanced Head Anchor Fairlead

AF-39 Marine Flange Mounted Balanced Head Anchor Fairlead – Certified Guide System for Safe Ship Mooring

Engineered for exceptional performance and durability, the AF-39 Marine Flange Mounted Balanced Head Anchor Fairlead is a critical component for modern vessel mooring systems. This precision-engineered fairlead expertly guides anchor cables and mooring ropes, changing their direction smoothly while minimizing wear and preventing damage. Its balanced head design ensures optimal force distribution, providing reliable operation even under the most demanding conditions.

Product Features & Quality Assurance

Superior Construction: Fabricated from high-grade materials including ZG230-450 cast steel and Q235 structural steel for maximum strength and impact resistance
Advanced Surface Treatment: Features abrasive blasting and epoxy coating for exceptional corrosion resistance in harsh marine environments
Precision Manufacturing: Produced using CNC machining centers, CNC lathes, and ultrasonic cleaning equipment for exacting tolerances and clean operation
International Certification: Supplied with major classification society certificates including CCS, BV, LR, ABS, and DNV-GL
Standard Compliance: Manufactured according to JISF, DIN, and GB standards, with custom designs available based on buyer specifications
Proven Durability: Excellent wear resistance ensures long service life with minimal maintenance requirements

Technical Specifications – AF-39 Anchor Fairlead

Wire Rope Dia.	Sheave Dia.	Dimensions (mm)						Mass Weight
mm	inch	mm	A	B	C	T	H	G	kg
25	1″	254	559	356	651	20	292	90	367
32	1-1/4″	305	711	508	862	30	343	100	612
38	1-1/2″	406	762	762	1233	40	459	150	918
44	1-3/4″	508	1067	914	1503	50	546	190	1700
50	2″	610	1219	1067	1775	50	648	220	2108
64	2-1/2″	762	1372	1219	2103	60	800	250	2465
