300kN Heavy-Duty Tugger Winch for Marine and Industrial Applications
The 300kN heavy-duty tugger winch is a high-performance mechanical system, expertly crafted to handle the rigorous demands of pulling, towing, and precisely positioning substantial loads in a wide array of industrial and marine settings. This winch is particularly optimized for maritime environments, where it serves as an indispensable tool in:
- Ship Docking and Mooring Operations: Ensuring secure and stable positioning of vessels during docking and mooring.
- Offshore Towing and Anchoring Tasks: Providing reliable force for towing and anchoring operations in offshore environments.
- Load Handling on Vessels and Offshore Platforms: Facilitating the safe and efficient movement of heavy cargo and equipment on various types of vessels and offshore platforms.
Built with precision engineering and a strong emphasis on safety, this tugger winch guarantees controlled force application, thereby enabling the smooth and efficient movement of cargo, equipment, or even entire vessels. To ensure accident-free operations and maintain optimal performance, it is crucial to provide operator training, adhere to proper load ratings, and follow strict safety protocols.
Construction Materials
- Aluminum: Renowned for its lightweight and corrosion-resistant properties, making it an excellent choice for marine applications.
- Stainless Steel: Offers exceptional marine-grade durability, ensuring longevity even in the harshest conditions.
- Carbon Steel: Provides high-tensile strength, making it suitable for heavy-duty operations that require robust performance.
Key Features & Benefits
- Robust & Reliable: Heavy-duty construction ensures dependable performance in the most demanding operations.
- Corrosion-Resistant: Designed to withstand harsh marine and offshore conditions, ensuring a long service life.
- Low-Maintenance Design: Features easy lubrication, inspection, and servicing, reducing downtime and operational costs.
- High-Efficiency Gearbox: Ensures smooth power transmission with minimal energy loss, enhancing overall efficiency and reducing fuel consumption.
- Customizable Configurations: Tailored to meet specific operational needs, such as load capacity and control systems, providing flexibility and adaptability.
- Optional Warping Head: Provides flexibility for diverse applications, expanding the winch’s usability across different industries.
- Dual Control Modes: Offers both local manual control and remote operation capabilities for enhanced convenience and operational flexibility.
- Clutch & Brake Options: Choose between manual or hydraulic systems based on operational requirements, ensuring safe and efficient operation.
- Motor Variants: Available with standard general-purpose motors or explosion-proof motors for hazardous zones, ensuring compliance with safety regulations.
- Advanced Monitoring: Optional auto-tension control and rope length/speed sensors for precise monitoring, enhancing operational safety and efficiency.
- Certified Compliance: Meets BV, LR, RINA, and other international standards, ensuring quality and safety in all applications.
Hydraulic and Electric Tugger Winch for Ship
- Product: Tugger winch/tugger capstan
- Capacity: 1T to 30T tugger winches; 0.5T to 20T tugger capstans
- Certificate: CCS, ABS, etc.
Tugger Winches/Capstans Specifications
| Model | HTW-10~300 | ETW-10~300 | HC-5~200 | EC-5~200 |
|---|---|---|---|---|
| Drive | Hydraulic or electric | Hydraulic or electric | Vertical | Vertical |
| Type | Single or double drum | Single or double drum | – | – |
| Rated load | 10KN~300KN | 10KN~300KN | 5KN~200KN | 5KN~200KN |
| Rated speed | 10~30m/min | 10~30m/min | 10~20m/min | 10~20m/min |
| Holding load | 20KN~500KN | 20KN~500KN | – | – |
| Dia. wire | φ13~42mm | φ13~42mm | φ13~32mm | φ13~32mm |
| Drum capacity | 50~500m | 50~500m | – | – |
| Clutch | Hydraulic/handle operated jaw type | Hydraulic/handle operated jaw type | – | – |
| Brake | Spring loaded hydraulic release/handle operated type | Spring loaded hydraulic release/handle operated type | – | – |
| Power required | 4~90kw | 4~90kw | 4~75kw | 4~75kw |
| Control | Local control & remote control in wheelhouse | Local control & remote control in wheelhouse | – | – |
| Option | Length & tension monitoring system | Length & tension monitoring system | – | – |
FAQs
Q1: What is the maximum load capacity of the 300kN heavy-duty tugger winch?
A1: The 300kN heavy-duty tugger winch has a maximum load capacity of 300kN, making it suitable for handling substantial loads in marine and industrial applications.
Q2: Can the tugger winch be customized to meet specific operational needs?
A2: Yes, the tugger winch offers customizable configurations to meet specific operational needs, such as load capacity and control systems, ensuring flexibility and adaptability.
Q3: What types of motors are available for the tugger winch?
A3: The tugger winch is available with standard general-purpose motors or explosion-proof motors for hazardous zones, ensuring compliance with safety regulations and suitability for various environments.
Q4: Does the tugger winch come with advanced monitoring features?
A4: Yes, the tugger winch offers optional advanced monitoring features, including auto-tension control and rope length/speed sensors, for precise monitoring and enhanced operational safety.
Q5: Is the tugger winch compliant with international standards?
A5: Yes, the tugger winch meets BV, LR, RINA, and other international standards, ensuring quality and safety in all applications.
Attention please: The description was copied from different cooperating manufacturers. The description may be different with the goods, please check with us when order.
