YSZ Series 15ppm Marine Bilge Oil Water Separator
The YSZ Series 15ppm Marine Bilge Oil Water Separator is a top – tier, marine – grade oil water separator specifically crafted to handle machinery space bilge water on ships. It is fully engineered in strict accordance with IMO Resolution MEPC.107(49), acting as both an oil content meter and a separation system. This ensures that the water discharged overboard meets the stringent ≤15ppm oil content standard set by international marine environmental regulations.
This separator is compact, highly efficient, and extremely reliable, offering a diverse range of treatment capacities to cater to various vessel sizes and different operational requirements. Its automated features, such as automatic oil discharge, heating controls, alarm systems, and operation recording, make it an ideal choice for modern, highly automated ships where ease of use and minimal maintenance are of utmost importance.
Key Features & Advantages
✅ IMO MEPC.107(49) Certified for Marine Compliance – Strictly adheres to the latest international marine environmental protection regulations, ensuring legal and environmental compliance for ship operations.
✅ High – Efficiency Three – Stage Filtration Separation – The three – stage filtration process guarantees an output with an oil content of ≤15ppm, providing clean and safe water discharge.
✅ Fully Automatic Operation for Convenience – Comes with auto oil discharge, self – monitoring, and alarm functions, reducing manual intervention and enhancing operational efficiency.
✅ Compact and Lightweight Design for Space Optimization – Its space – saving design does not compromise on treatment capacity, making it suitable for ships with limited space.
✅ Low Maintenance Requirements for Cost – Effectiveness – Easy access for inspection, cleaning, and part replacement, minimizing downtime and maintenance costs.
✅ Multi – Voltage Compatibility for Global Use – Compatible with both 3Ph/380V/50Hz and 3Ph/440V/60Hz power supplies, enabling use in different regions around the world.
Available Models & Technical Specifications
| Model | Treatment Capacity (m³/h) | Motor Power (kW) | Electric Heating (kW) |
|---|---|---|---|
| YSZ – 0.1 | 0.1 | 0.12 | – |
| YSZ – 0.25 | 0.25 | 0.18 | – |
| YSZ – 0.5 | 0.5 | 0.25 | 1 |
| YSZ – 1.0 | 1.0 | 0.37 | 2 |
| YSZ – 2.0 | 2.0 | 0.75 | 2 – 3 |
| YSZ – 3.0 | 3.0 | 1.1 | 3 |
| YSZ – 4.0 | 4.0 | 1.5 | 3 |
| YSZ – 5.0 | 5.0 | 1.5 | 3 |
Discharge Standard: ≤15ppm (IMO MEPC.107(49))
Working Pressure: ≤0.3MPa
How It Works – Three – Stage Oil – Water Separation Process
- Gravity Separation Stage: Bilge water first enters the initial chamber. Here, large oil droplets are separated from the water through the natural force of gravity, allowing the heavier water to sink and the lighter oil to float.
- Coalescing Filtration Stage: Smaller oil particles (≥0.5µ) in the water are then aggregated into larger ones using a coalescer. This makes it easier to remove these oil particles from the water, further purifying the mixture.
- Final Polishing Stage: If necessary, a third – stage dialysis unit is employed. This unit ensures that even emulsified oils are extracted from the water, achieving a consistent ≤15ppm purity level. The collected oil is automatically discharged to the sludge tank, enabling continuous operation with minimal manual intervention.
Maintenance & Troubleshooting
Routine maintenance of the YSZ Series separator is straightforward and simple:
- Weekly Suction Filter Cleaning: Regularly clean the suction filter on a weekly basis to prevent blockages and ensure smooth water intake.
- Regular Pump and System Inspection: Inspect the pump condition, pressure readings, and oil discharge mechanisms regularly to identify any potential issues early on.
- Periodic Coalescer and Dialysis Element Checks: Check the coalescer and dialysis elements periodically to ensure they are functioning properly and replace them if necessary.
Common issues such as pump failure, filter blockage, or alarm malfunctions can be quickly resolved using the included troubleshooting guide and maintenance manual, minimizing downtime and ensuring the continuous and efficient operation of the separator.
